Four sided planers Leadermac HYPERMAC 930 2021

Description

- Year: 2021
- Documentation available: Yes

- └ Type Documentation: Operating system, User manual, Electrical diagrams, Technical data

- CE marking present: Yes
- CE certificate present: Yes
- Serial number: 2010016
- Number of spindles [pcs.]: 9

- └ Spindle 1:

- - Spindle type: Bottom
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes

- └ Spindle 2:

- - Spindle type: Right
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes

- └ Spindle 3:

- - Spindle type: Left
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes

- └ Spindle 4:

- - Spindle type: Top
- - Motor power [kW]: 15
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes

- └ Spindle 5:

- - Spindle type: Right
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes

- └ Spindle 6:

- - Spindle type: Left
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes

- └ Spindle 7:

- - Spindle type: Top
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000

- └ Spindle 8:

- - Spindle type: Bottom
- - Motor power [kW]: 15
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes

- └ Spindle 9:

- - Spindle type: Universal
- - Motor power [kW]: 11
- - Spindle diameter [mm]: 50
- - Cutterhead speed [rpm]: 6000
- - Tool present: Yes

- Min. planing width [mm]: 20
- Max. planing width [mm]: 300
- Min. planing height [mm]: 10
- Max. planing height [mm]: 200
- Feed speed: Automatic

- └ Min. feed speed [m/min]: 6
- └ Max. feed speed [m/min]: 36

- Transport dimensions: 7100mm x 2200mm x 1900mm (l x w x h)
- Transport weight [kg]: 12000kg
- Transport packages [pcs.]: 1
