Telescopic Loader GG016T

Description

GG016T

Weight 4000 kg
Engine Diesel
Max. travel speed 18-28 km/h
Height 2580 mm
Load capacity 1600 kg
Engine speed 2400 rpm
Length 5480 mm
Width 1850 mm

GG016T
Telescopic Loader
The Gunter Grossmann GG016T telescopic loader is an efficient and sturdy machine designed for use in demanding construction, agricultural, and industrial conditions. With high power, modern technological solutions, and exceptional versatility, the GG016T model ensures reliability and efficiency in a variety of tasks. This machine excels at moving and lifting heavy materials as well as performing tasks in tight spaces.

Engine and Drive – Efficiency and Reliability

The GG016T is equipped with a diesel engine that provides high power and reliability in any conditions. With a rated speed of 2400 rpm, the engine delivers the necessary power to perform heavy-duty tasks. This model offers a maximum speed range of 18-28 km/h, providing good mobility on construction sites and other working conditions. The use of tires such as 20.5/70-16 (standard) and optionally 33X16.5-15 ensures excellent traction and comfort when working in tough terrain.

Hydraulics – Power and Efficiency

With a hydraulic pressure of 16 MPa and a hydraulic oil flow of 60 l/min, the GG016T is capable of performing tasks requiring high hydraulic power. The high efficiency of the hydraulics allows for fast and effective operations, giving the user full control over the machine. The hydraulic system works perfectly with the 0.8 m³ bucket capacity, allowing for the movement of larger quantities of material in a shorter time.

Work Range – Efficiency and Versatility

With a load capacity of 1600 kg, the GG016T is ideal for working with heavier materials. The machine features a compact design and a short wheelbase (1500 mm), which ensures exceptional maneuverability, especially in narrow workspaces. The speed range of 18-28 km/h allows for quick movement across the work site, accelerating task completion. Additionally, the 0.8 m³ bucket capacity enables efficient loading and unloading of materials, making
