Branson TYM 2505 hydrostatic
Basic information
Description
If you are looking for a reliable compact tractor, then the Branson 2505h with its 25 HP water-cooled 4-stroke diesel engine with a hydrostatic transmission is the right choice for you. User-friendliness, manoeuvrability and wide applicability are what the Branson 2505H excels at. In addition, running and maintenance costs are relatively low.
The Branson 2505h can be equipped with, among other things, a mid-mounted mower, front loader or rear loader. The Yanmar diesel engine meets all EPA Tier V requirements. The engine runs in a quiet and clean manner.
Specifications:
Engine
- 25 HP, 3-cylinder Yanmar Stage V
Drive
-2 groups Hydrostatic
-Max. speed 18 km/h
-4WD electrically engageable
Hydraulics & PTO
540 rpm rear power take-off
-2000 rpm centre PTO
-Standard 1 D.W. valve
-Cat. I lift with 600 kg lifting capacity
-Oil pump capacity 15.8 l/min
Length: 2,649 mm
Width: 1,190 mm
Height: 2,320 mm
Track width: 1,461 mm
Ground clearance: 270 mm
Unladen weight: 768 mm
