NorAn N-MAX BS Cultan 4.75 liquid injector

Description

Efficient and Precise Nutrient Application
The NorAn N-MAX liquid fertilizer injector is one of the most innovative tools available on the market for nutrient replenishment. This is well demonstrated by the fact that our injector won the "Hungarian Agricultural Machine of the Year 2021 Innovation" award. As one of the first in Europe, the N-MAX provided farmers with the opportunity to efficiently apply easily absorbable liquid fertilizer in the root zone of corn and sunflower crops at high operational speeds after sowing.
Building on this innovation, we have further developed the system to not only be suitable for row crops but also for grain crops by delivering nitrogen directly to the plant roots. The application is carried out in small doses at 25 cm row spacing, ensuring no plant damage. Measured results show that this technology can achieve a 30% reduction in top-dressing fertilizer use in grain crops. In corn and sunflower, specific rows can be closed off for more efficient application.
Place Your Nitrogen Where and When It Truly Matters – in an Immediately Available Form!
With the NorAn N-MAX Cultan fertilizer injector, you can apply fertilizer precisely where and when your plants need it the most. Granular fertilizer remains unavailable until it receives moisture, which is why more and more farms are switching to liquid fertilizers.
This ensures that plants absorb more nitrogen while reducing losses due to evaporation and leaching into groundwater. This system minimizes soil moisture loss and maximizes nutrient utilization.
Hungarian Engineering with Western Quality!
✅ 2-YEAR FULL MANUFACTURER WARRANTY! (excluding wear parts)
Recommended for the following crops:
-Cereals
-Corn
-Sunflower
-Tomato
-Rapeseed
Technical Specifications & Standard Equipment:
-Available in 19-row and 25-row configurations (covering 6 or 8 corn rows)
-KAT2 and KAT3 mounting
-Hydraulic folding
-Robust 150x150 mm closed-profile frame
-Expandable frame design
-Fully stainless steel fasteners
-85 cm clearance height
-51 cm diameter OFAS discs with maintenance-free bearings
-Large-diameter stainless steel application wheel
-Speed-proportional control
-Annovi Reverberi 115 L/min pump
-Arag fittings and valves
-Self-priming system
-1100 L tank capacity
-Tank mounted on an independent bracket for adjustable positioning
-Speed tracking via GPS signal
-ISOBUS control system
-Automatic shut-off at headland turns
-Stepless adjustable gauge wheels (23x10.5-12) for depth control
-Stepless adjustable coulter spacing
-Application rate adjustable between 100-400 L/ha
-Hand wash tank
-PTO shaft
-Road lighting
Optional Accessories:
-NorAn MultiTank front-mounted auxiliary tank
-Closing wheel set behind the coulters
-Visual flow indicator
-Suction hose
-Additional nozzle kit
-Hydraulic motor pump option instead of PTO pump
2024 Pricing (Base Configuration):
Without tank:
-NorAn N-MAX WT Cultan 4.75: €34,486 + VAT (6 x 75 cm)
-NorAn N-MAX WT Cultan 6.25: €43,311 + VAT (8 x 75 cm)
With 1100 L tank included:
-NorAn N-MAX BS Cultan 4.75: €39,177 + VAT (6 x 75 cm)
-NorAn N-MAX BS Cultan 6.25: €48,003 + VAT (8 x 75 cm)
Without tank + NorAn MultiTank HF 1100 L (Hydraulic Motor) Front Tank:
-NorAn N-MAX SP Cultan 4.75: €42,133 + VAT (6 x 75 cm)
-NorAn N-MAX SP Cultan 6.25: €50,958 + VAT (8 x 75 cm)
Orders are invoiced in Euros or in Hungarian Forints at the MNB exchange rate on the day of fulfillment.
🚛 FREE DELIVERY ACROSS HUNGARY!
